The International Organization for Standardization (ISO) is in development of the new ISO 80369 standards to reduce the risk of misconnections between small-bore medical connectors. These connectors are used in respiratory, enteral, urinary, blood pressure, neuraxial and intravenous systems which historically used an identical luer lock design.
This increases the likelihood of a misconnection between the delivery systems used in the medical device industry. We have seen the impact of these new standards which has led to new designs, new parts, new molds, and the replacement of millions of components. The FDA is reviewing the deadline for ISO 80369 enforcement. Injectech is proud to manufacture panel mounts, barbed luers, bond-in luers, filters and check valves that meet the ISO 80369-7 standard.
Functionality and tested for:
• Sub-atmospheric-pressure air leakage
• Stress cracking leakage
• Resistance to separation from axial load
• Resistance to separation from unscrewing
• Resistance to overriding
• Selected materials have a modulus of elasticity of over 700 MPa
Injectech has started with Acrylic, Polycarbonate, and ABS. We will continue with Kynar, Polypropylene, and Nylon. We have performed testing on both barbed and bond-in luers with slip luers, rotating luers and couplers to follow.
Within the coming months, the FDA plans to publish Amendment 1 to the 80369-7 standard and will no longer be accepting device designs for intravascular or hypodermic applications that incorporate luer connectors of the ISO 594 standard after that time. Be proactive and start incorporating these luers into your devices today!
We recommend caution when others designate their parts as 80369-7 compliantwithout offering sufficient evidence to back their claims.It is highly recommended that your suppliers have the appropriate test results to back their claim to the ISO 80369-7 standard to avoid future issues with the FDA.
Our ISO 80389-7 products - Look for this symbol
70418From $0.13Multiple options available
70214From $0.15Multiple options available
702116From $0.12Multiple options available
80369-7 Female Luer Lock to 1/16" Barb (1.5mm) ID Tubing - Clear ABSFrom $0.12Multiple options available
A guide to ISO 80369
• ISO 80369-1 General requirements for small bore connectors - Published
• ISO 80369-2 Respiratory (Breathing Systems)
• ISO 80369-3 Enteral Feeding - Published
• ISO 80369-4 Urinary and Urethral
• ISO 80369-5 Blood Pressure (Limb Cuff Inflation) - Published
• ISO 80369-6 Neuraxial Devices - Published
• ISO 80369-7 Intravascular (IV) or Hypodermic - Published
Are you interested in learning more? Call us at Injectech and we will discuss how this could affect your project and how we can help!
